General
| Product Name | Â handheld portable dental X-ray cmos camera machine |
|---|---|
| Function | dental X-ray |
| Certification | CE |
| Warranty | 3 Years |
| After Sales Service | after-sale technical support |
Details
| Material | Acrylic, Metal |
|---|---|
| Sensor Technology | APS CMOS |
| Ingress Protection | IP68 for Soak disinfection |
| Additional | Support TWAIN protocol |
| Power Source | Electric |
| Instrument classification | Class II |
| Scintillator | Directly deposited CsI:Tl |
| Exposure Mode | Smart AED |
| Features |
|
Specification
| Pixel Pitch (μm) | 20 |
|---|---|
| Shelf Life | 1 year |
| Data Interface | Wireless IEEE 802.11 2.4GHz / 5.8GHz |
| Operation System | Windows 7 and above, 32 / 64 bit |
| Gray Level | 16 bit |
| Mechanical Dimensions (mm) | 30.4 × 41.9 × 4.5 |
| Active Area (mm²) | 26 × 36 |
| Pixel Matrix | (2.34 M) 1300 × 1800 |
| Length of Cable (m) | Standard 3m / Option 5m |
