General
| Product Name | Blood Glucose Monitoring System |
|---|---|
| Function | intended for external use only and widely applied in monitoring blood glucose |
| Certification | CE |
| Warranty | 1 Year |
| After Sales Service | after-sale technical support |
Details
| Intended Use | It is intended for IVD testing the blood glucose in the fresh whole capillary blood and vein plasma; for medical institutes’ fast testing of blood glucose; for diabetics and other groups’ blood glucose monitoring. |
|---|---|
| Test Principle | C6H12O6 + K3Fe(CN)6 → FAD-GDH → C6H12O7 + K4Fe(CN)6 K4Fe(CN)6 → K3Fe(CN)6+ e- |
| Features |
|
Specification
| Blood volume | 0.6μL |
|---|---|
| Sample type | Capillary whole bloodyenous whole blood |
| Calibration | Plasma equivalent |
| Measuring time | 10s |
| Meter storage/transportation condition | -20℃~55℃ |
| Dimension | 105*60*23（mm） |
| Weight | 77.2g,with battery |
| Power source | 3V DC,10mA,2 AAA alkaline batteries |
| Memory | 200 blood glucose test results |
| Operating condition | 10℃~35℃; ≤80% RH |
| Construction | Hand-held |
| Measurement units | mg/dL or mmol/L |
| Measurement range | 20~600 mg/dL or 1.1～33.3mmol/L |
