Medical Aluminum Oxygen Cylinder
Medical/industrial gas cylinders use with Aluminum seamless Cylinders instead of steel ones with weight reduction of 40%-70%, safe and easy to carry.Oxidation of aluminum by a unique corrosion resistance,can store more oxygen/CO2/AIR/N2O in clean,no smell,There are easy-to-user’s health.These cylinders also can be designed and processed in strict accordance with the standards of BS, JIS, DIN, EN, KS, ISO, GB(China) or the off-standard from the consumer.
General
| Product Name |
4L 10L Hot Sale Medical Aluminum Oxygen Cylinder |
| Function |
Storage Pressure Vessel,industry,Laboratory research,Industry and Medical treatment |
| Certification |
DOT, TUV, GB5099,ISO9809,GB11640,CCS, BV, ABS, TC,& LIOYGS |
| Warranty |
/ |
| After Sales Service |
Technical Support |
Details
| Cylinder Standard |
DOT/TUV/GB11640 |
| Material |
Aluminum |
| Application |
Gas |
| Storage Medium |
Moncombustible/Nontoxic |
| Color |
White/Black/Green/Blue/Other to Be Confimed |
| Accessories |
Cap/Valve Handle/Valve |
| Features |
- Medical Aluminum Oxygen Cylinder 10L
|
Specification
| Pressure |
10.0MPa≤p<100.0MPa |
| Pressure Level |
High Pressure (10.0MPa≤p<100.0MPa) |
| Working Pressure |
15/20MPa |
| Gas Service |
O2/Air/N2/Argon/CO2 |
| Mouth Thread |
Pz27.8/3/4-16 Unf |
| Specification |
DOT/TUV/GB11640 |
| Water Capacity |
10L |
| Test Pressure |
25MPa/30MPa |
| Diameter |
140/159mm |
