NIBP Simulator
- CE certification
- Warranty
- After-sale Service
Specifications
- Description
Description
General
| Product Name | NIBP Simulator |
|---|---|
| Function | For testing NIBP Monitor adopted Oscillometry |
| Certification | CE |
| Warranty | 1 Year |
| After Sales Service | after-sale support |
Details
| Features |
|
|---|
Specification
| Systolic pressure | 2.7 kPa (20 mmHg) ~ 40.0 kPa (300 mmHg) |
|---|---|
| Diastolic pressure | 1.3kPa (10 mmHg) ~ 33.3 kPa (250mmHg) |
| Pulse volume | 0.1 cc ~ 2.4 cc |
| HR range | 30 bpm ~ 250 bpm |
| pulse volume | > 2.00 cc |
| maximum HR | 200 bpm |
| HR accuracy | ± 1 bpm |
| Output range | 6.7 kPa (50 mmHg) ~ 53.3 kPa(400 mmHg) |
| Resolution | 0.1 kPa, 1 mmHg, 1 cmH2O, 1 inH2O, 0.1 psi |
| Power supply | AC100 ~ 240 V 50/60 Hz, <60 VA |
| Dimension | 207 (L) × 220 (W) × 121 (H) mm |
| Weight | 2.1kg |
